EW/ECM EQUIPMENT

SAJ-2000MD

DIGITAL BROADBAND JAMMER


COMJAM application, EW/ECM
Portable for various platforms including airborne and shipboard installations
Frequency range 0.1 MHz up to microwave or per separate specification
Up to 1 kW RF output power, adjustable
Ultra-fast digital synthesizers
Multi-threat and multi-mode operation
High speed search-lock receiver interface
Various operational modes including real-time spoofing
Manual and fully automatic operation
Programmable exclusion of unlimited communication channels or sub-bands
Broadband or spot jamming including programmable fast frequency hopping
Download of frequency lists for programmed spot jamming from a search receiver
Synthesizer parameters fully programmable using a PC/Notebook
Comfortable GUI Graphic User Interface for operator
Remote control via TCP/IP, encrypted VPN or protected radio link
Comprehensive BITE test
Wide range DC and AC power supply
According to MIL-STD-810F and DO-160F

SAJ-2000MD Application Example for German Airforce
Fact Sheet for SAJ-2000MD
Further Information

SAJ-2010MD

DIGITAL BROADBAND JAMMER


Mobile and portable
Frequency range 25 to 512 MHz or per separate specification
100W (CW) RF output power, adjustable
Only one antenna is required
Ultra-fast digital synthesizer
Broadband or spot jamming including lists
Programmable fast frequency hopping
Various operational modes including spoofing
Programmable exclusion of unlimited friendly communication channels or sub-bands
High speed search-lock receiver input
Download of frequency lists for programmed jamming from a search receiver
Remote control via encrypted radio link
Jamming parameters fully programmable using a PC/Notebook or local keypad
Comfortable GUI Graphic User Interface for operator
Comprehensive BITE test
External power supply: 24/28 VDC or 115/230 VAC
According to MIL-STD-810F

Fact Sheet for SAJ-2010MD
Further Information

SAJ-1010

COMMUNICATION JAMMER
Quad-band


Protection of limited areas
Customised frequency bands from HF to SHF
Plug-in frequency modules
Medium output power up to 30 W
Simple operation
High performance
Compact size
Rugged, watertight construction
Customised jamming waveforms or frequency ranges
According to MIL-STD 810F and IP-67

SAJ-1010 Communication Jammer (Quad-band)
Fact Sheet for SAJ-1010
Further Information

SAJ-1030

INTELLIGENT GPS JAMMER


Programmable GPS spoofing
Operation modes: Deception/Confusion/Denial
Difficult to localise
Remotely-programmable position info offset
Protects limited geographical areas
Protects against GPS guided weapons and UAVs
Adjustable high power output
Remote control over air
Simple operation
High performance
Compact size
Rugged, watertight construction
According to MIL-STD 810F

SAJ-1030 Intelligent GPS Jammer
Fact Sheet for SAJ-1030
Further Information
